Megawatt Charging for Electric Logistics Trucks

MAN Truck & Bus is releasing the eTGX and eTGS battery-electric trucks, which are the first European production vehicles equipped with the Megawatt Charging System (MCS). This commercial vehicle-specific charging technology is designed for the road freight transport industry, enabling shorter charging times and supporting the development of a high-performance logistics automotive data ecosystem.

Megawatt Charging System Specifications and Performance
The MCS technology enables significantly higher charging capacities compared to the currently established Combined Charging System (CCS). While CCS infrastructure limits commercial vehicles to 375 kW, the new MCS-equipped trucks achieve charging capacities of up to 750 kW, operating at up to 1,000 amps and 750 volts. For a battery configuration of six packs totaling 534 kWh of capacity, the MCS hardware can elevate the state of charge (SoC) from 20% to 80% in under 30 minutes. Chassis models utilizing a seven-battery configuration with a 623 kWh total capacity can reach an 80% SoC in under 40 minutes. These metrics allow operators to recharge the vehicles during legally mandated driving breaks, resulting in higher asset utilization.

Operational Range and Charging Port Architecture
With individual ranges reaching 570 kilometers between charging stops, long-haul semi-trailer trucks can achieve a daily operational range exceeding 1,000 kilometers within standard working hours. To ensure interoperability across various charging infrastructures, the vehicles integrate multiple physical charging interfaces. The primary MCS port is located on the front left of the vehicle, while optional CCS ports can be positioned on the front right, as well as the rear right and left on chassis models. Roman Sitte, Head of Sales Area Europe, noted that the deployment of these vehicles contributes to establishing the new charging standard in Europe and strengthening interoperability within the overall digital supply chain system.




Market Deployment and Consulting Services
Initial series-produced vehicles from the Munich assembly plant are scheduled for phased delivery to transport operators in Belgium, Denmark, Germany, Great Britain, Italy, the Netherlands, Norway, Spain, and the Czech Republic. The manufacturer integrates available and planned MCS charging nodes into its consulting services to optimize route planning for heavy-duty fleets. Additionally, operators utilize a proprietary charging service to access tested and verified MCS and CCS charging points across the European network.

Additional Context
This section details technical specifications and competitive benchmarking not included in the original news release.

Within the European heavy-duty electric vehicle market, the implementation of MCS serves as a primary differentiator for operational viability in long-haul logistics. The MAN eTGX and eTGS compete directly with models such as the Mercedes-Benz eActros 600 and Scania's regional long-haul battery-electric trucks. The Mercedes-Benz eActros 600 features a battery capacity of over 600 kWh and is engineered for MCS charging at approximately 1,000 kW (1 MW) pending the finalization of the megawatt standard, which is projected to allow a 20% to 80% charge in roughly 30 minutes. Scania’s current heavy-duty electric trucks utilize 375 kW CCS inputs but are mechanically slated for future 750 kW to 1 MW MCS upgrades. By commencing series production of the eTGX and eTGS with an operational 750 kW MCS architecture, MAN establishes an early benchmark in verifiable charge speeds for European series-production logistics vehicles, accelerating the transition from standard CCS limitations prior to the full 1 MW+ rollout of the broader MCS protocol.

Edited by Aishwarya Mambet, Induportals Editor, with AI assistance.

www.man.com
